Mavic has unveiled its lightest Crossmax wheelset to date, the Crossmax Ultimate, engineered for elite cross-country (XC) racing. Weighing a mere 1,080 grams per pair, these wheels are designed to deliver explosive acceleration, precise handling, and podium-worthy performance. (bikerumor.com)
Adaptive Layup Carbon Rims
The Crossmax Ultimate features Mavic’s Adaptive Layup technology, optimizing carbon fiber layers to balance stiffness, vibration damping, and weight. The rims have a 30 mm internal width and a 25 mm depth, providing stability under load and precision at high speeds. This design is tailored for modern XC tires, with a recommended size range of 2.3″ to 2.4″. (bikerumor.com)
UltraLight Hubs
Central to the wheelset are Mavic’s new UltraLight Hubs, weighing 105 grams for the front and 180 grams for the rear in the XD 6-bolt configuration. These hubs are equipped with Mavic’s precise, low-friction ceramic bearings and feature the 40-tooth ID360 LIGHT ratchet system for quick engagement, ensuring efficient power transfer and responsiveness. (bikerumor.com)
Carbon Spokes with Titanium Nipples
The wheelset employs 20 straight-pull carbon spokes per wheel, arranged in a 2-cross pattern. This configuration offers an optimized stiffness-to-weight ratio and natural vibration damping properties. Titanium nipples further reduce rotational weight, enhancing acceleration and overall performance. (bikerumor.com)
Proven Performance
The Crossmax Ultimate wheels have been tested in the competitive arena, with riders from the Mondraker and KTM Factory XC teams using them since the start of the 2026 season. Notably, Katrin Embacher secured a U23 XCO victory, and the wheels have contributed to multiple top-10 Elite performances. (bikerumor.com)
Specifications
- Rim Width: 30 mm internal, 36 mm external
- Rim Depth: 25 mm
- Rim Type: Carbon, hookless
- Recommended Tire Size: 2.3″ – 2.4″
- Materials: T700, T1000, 3K carbon fibers with Adaptive Layup
- Spokes: 20 carbon spokes per wheel, 2-cross pattern
- Nipples: Titanium
- Hubs: UltraLight Hubs
- Spacing: 15 x 110 mm front, 12 x 148 mm rear
- Bearings: Mavic Ceramic
- Brake Interface: Centerlock and 6-bolt
- Freehubs: XD and Microspline
- Freewheel System: ID360 Ultralight 40T
- Weight: 500 g front, 580 g rear, 1,080 g total
- ASTM Level: 3
- Max Rider Weight: 135 kg
- Included Accessories: Tubeless valves, tubeless tape, wheel bags
Pricing and Availability
The Mavic Crossmax Ultimate XC race wheels are priced at €2,299. For more information, to check availability in your region, or to find a dealer near you, visit Mavic’s official website. (bikerumor.com)
With the Crossmax Ultimate, Mavic continues to push the boundaries of XC wheel performance, offering a lightweight and reliable option for riders aiming for the top step of the podium.
